Infinity Pool: Design, Construction, and Waterproofing
The infinity pool, also known as an infinity edge pool or negative edge pool, has become one of the most sought-after designs in luxury homes, boutique hotels, and high-end resorts throughout Spain. Its visual effect, where water appears to merge with the horizon, creates an incomparable aesthetic impact. However, behind that beauty lies precise engineering and demanding waterproofing that you should understand before undertaking the project.
What exactly is an infinity pool?
Unlike a conventional pool with raised edges, the infinity pool has at least one side at the same level as the water surface. Water overflows continuously and in a controlled manner toward a perimeter channel or edge skimmer, from where it is collected and returned to the main pool shell via a compensating reservoir. This reservoir acts as a buffer: it absorbs the volume of water displaced by swimmers and returns it when the pool is empty of people.
The circulation system is more complex than in a standard pool because it must handle large volumes of water in continuous circulation. The pump works longer hours, the filtration is more intensive, and the hydraulic design requires precise calculations so that the visual effect is uniform across the entire overflow edge.
Design and location considerations
Location is fundamental. Infinity pools maximize views from elevated areas: a country estate in the Sierra de Ronda, a villa overlooking the Costa del Sol, or a penthouse in Seville are ideal scenarios. The terrain must allow for the construction of the compensating reservoir, generally located beneath the overflow area, which implies additional excavation and higher structural costs.
The water level must be maintained with millimetric precision. A variation of just a few centimeters can ruin the visual effect or cause uncontrolled overflows. That is why automatic level control systems are essential in this type of installation.
Why reinforced liner is the ideal solution for infinity pools
Waterproofing is the most critical technical aspect of an infinity pool. Perimeter channels, corners, connections between the main pool shell and the compensating reservoir, and curved or irregular surfaces are points of hydraulic stress that demand a highly flexible and durable waterproofing material.
PVC reinforced liner offers decisive advantages in this context. Its flexibility allows it to adapt to complex geometries without rupture points. Unlike mosaic tile or paint coatings, which require expansion joints and are vulnerable at corners and edges, reinforced liner forms a continuous and homogeneous membrane that covers the entire wet surface, including overflow channels.
The resistance of reinforced liner to temperature changes is especially valuable in Andalusia, where thermal fluctuations between winter and summer are significant. PVC absorbs these movements without cracking, something that rigid coatings cannot guarantee.
Moreover, if a localized repair becomes necessary—for example, an accidental cut during maintenance work—the liner can be welded in place quickly and often without completely draining the pool.
Cost comparison versus traditional pool
An 8x4 meter infinity pool in Andalusia can cost between 30% and 60% more than a conventional pool of the same dimensions. This difference is explained by the greater excavation required, the compensating reservoir, the more complex hydraulic system, and the finishes of the overflow edge. However, the aesthetic value and real estate appreciation that it provides justify the investment for many property owners.
Maintenance is also somewhat more demanding: the water level must be checked more frequently, the pumping system consumes more energy, and the overflow channels require periodic cleaning to prevent algae and lime accumulation. A quality reinforced liner significantly reduces long-term maintenance costs by eliminating filtration problems and the need for periodic recoatings.
Specific maintenance of the infinity pool
Review of the perimeter channel should be performed monthly during the use season. The compensating reservoir must be kept at appropriate levels and checked at the start of each season. Reinforced liner requires no special treatments beyond routine water cleaning, but an annual visual inspection is recommended to detect any premature abrasion or wear.
If you are thinking about building an infinity pool or retrofitting your existing one with reinforced liner, at ArgPiscinas we are specialists with over two decades of experience in high-end installations throughout Andalusia. Request your quote without obligation at argpiscinas.es and we will advise you from design through final installation.
